Legendary Warn Recovery: Warn offers the most reliable winch in the marketplace. A winch is only good when it works when you are in a bind. There is nothing worse than trying to use a winch that has been sitting on the front of your Jeep for months and your stuck in that nasty mud hole with a defective winch that does not work. The Warn brand name is know world wide for dependable winches that you can trust with endless reviews and customers proving it.
Trail Ready Ultimate Pulling Power: The 8,000 lb winch offers fast, efficient pulling power, while the 10,000 lb winch has the perfect blend of speed and power. Then there is the 12,000 lb winch that is made for heavier loads and those larger vehicles. The perfect blend of options for every application.
2-in-1 Wired/Wireless Remote: The re-designed remote offers the option to go wireless giving you more versatility and function. Also including an 11.5 foot lead when needed for backup or for the old school guys that want it hard wired. Making this winch very user friendly.
Standard Mounting Bolt Pattern: 10.0" x 4.5" (254mm x 114.3mm)
Overall Winch Dimensions: 21" L x 6.3" D x 10.1" H (534mm L x 160.5mm D x 256mm H)
| VR EVO 10, VR EVO 10-S SPECS/PART NUMBERS |
|
Part Numbers: PN 103252 (VR EVO 10), 103253 (VR EVO 10-S) |
|
Rated Line Pull: 10,000 lbs (4536 kgs) |
|
Motor: 12V DC, Series Wound™ |
|
Electrical Controls: Albright Contactor |
|
Remote Control: 2-in-1 plug in remote with wireless capability and 11.5' (3.5m) Lead |
|
Geartrain: 3-Stage Planetary |
|
Gear Ratio: 218:1 |
|
Clutch (freespooling): Rotating Ring Gear Clutch |
|
Brake: Spring Brake |
|
Drum Diameter/Length: 2.5"/9.0" (6.73cm/23cm) |
|
Weight: Shipping Steel - 91.93 lbs (41.7 kgs), Shipping Synthetic - 72.40 lbs (32.84 kgs) |
|
Rope: Steel - .354" x 90' (9mm x 27.4m), Synthetic - 3/8" x 90' (9.5mm x 27.4m) |
|
Fairlead: Steel - Roller, Synthetic - Die Cast Hawse |
|
Recommended Battery: 650 CCA min. for winching |
|
Battery Leads: .098" x 6.5' (25mm x 2m) |
|
Finish: Powder coat finish over primer undercoat |
|
Warranty: Limited Lifetime |
| VR EVO 10, VR EVO 10-S: 12V DC Performance Specs (based on first layer of drum) |
Line Pull
Lbs (Kgs) |
Line Speed
Ft/min (M/min) |
Motor
Current |
Pull by layer
layer/Lbs (Kgs) |
| 0 |
27.1 (8.3) |
58 amps |
1/10000 (4536) |
| 2000 (910) |
13.9 (4.2) |
125 amps |
2/8226 (3731) |
| 4000 (1810) |
9.9 (3.0) |
185 amps |
3/6987 (3169) |
| 6000 (2720) |
8.2 (2.5) |
244 amps |
4/6072 (2754) |
| 8000 (3630) |
6.5 (2.0) |
303 amps |
5/5370 (2436) |
| 10000 (4536) |
5.2 (1.6) |
358 amps |
|
